Dab tsi yog qhov muaj pes tsawg leeg ntawm lub tsev cog khoom ntse ntse ntse tsev cog khoom
Lub tsev cog khoom ntse yog lub ntsiab lus dav dav (tsis yog lub npe tshaj lij) rau Dutch Venlo tsev cog khoom thiab lwm lub tsev cog khoom nrog cov kev tswj xyuas ntse. - Feem ntau yog hais txog lub tsev cog khoom ntse uas nws lub ntsiab qauv yog Dutch Venlo tsev xog paj (ob chav slope, herringbone ridge), npog nrog iav los yog PC board rau thermal rwb thaiv tsev, thiab nruab nrog nplua nuj sunshade system, cua txias system, yuam cua tshuab, ntuj cua qhov system. , cua sov system, ntxiv teeb pom kev zoo, ntse tswj system, sprinkler irrigation system, seedbed system thiab lwm yam advanced chaw thiab khoom siv tau zoo heev txhim kho efficiency ntawm ntau lawm kev tswj, tshwj xeeb tshaj yog ntxiv rau Internet ntawm tej yam ntse tswj system, uas ua rau cov kev tswj efficiency. ntawm lub tsev cog khoom ntse ntse dua Nws yog qhov tseeb dua thiab txo cov kev nyuaj thiab qhov pib ntawm kev tswj tsev cog khoom. Nws yuav tsum tau taw qhia tias yog "tsev cog khoom ntse" tsis muaj IoT ntse tswj system, hais nruj me ntsis, nws tsuas yog lub tsev cog khoom zoo tib yam nrog lub tsev cog khoom ntse.
Cov muaj pes tsawg leeg ntawm ntse tsev xog paj
1. Tsev cog khoom
Muaj ntau ntau hom tsev cog khoom, thiab cov qib ntawm kev txawj ntse tswj uas tuaj yeem ua tiav kuj yog qhov sib txawv vim muaj cov qauv sib txawv. Lub tsev cog khoom yooj yim tshaj plaws kom paub txog kev tswj hwm kev txawj ntse ntawm Internet ntawm Yam yog lub tsev cog qoob loo ntau yam, uas tuaj yeem muab qhov chaw zoo thiab tswj tau kev loj hlob rau cov qoob loo.
2. Cov ntaub ntawv tso saib
Cov ntaub ntawv tso tawm ntawm Internet ntawm Tej yam ntse tsev cog khoom yog feem ntau muab faib ua ob peb ntu: (1) Cov ntaub ntawv tso saib thaj chaw tsim los ntawm LCD npo hauv tsev cog khoom. (2) PC lub computer davhlau ya nyob twg cov ntaub ntawv qhia. (3) Chaw taws teeb saib xyuas lub sijhawm ntawm lub xov tooj ntawm tes. Peb txoj kev tso saib no txhua tus sau cov ntaub ntawv los ntawm cov sensors thiab cov koob yees duab hauv tsev cog khoom, thiab nthuav tawm cov ntaub ntawv ntawm qhov chaw thiab scenes, uas yooj yim rau kev tswj hwm thiab kev ua haujlwm.
3. Sensor
Cov sensors ntawm IoT ntse tsev cog khoom feem ntau muaj xws li: huab cua kub thiab av noo sensors, av kub thiab av noo sensors, av PH sensors, lub teeb sensors, koob yees duab, thiab lwm yam Sensors kuj muab faib ua wired thiab wireless hom raws li txawv designs. Lub IoT ntse tswj system sau cov ntaub ntawv los ntawm cov sensors, xws li huab cua kub thiab av noo, av kub thiab av noo, av PH nqi, lub teeb siv, carbon dioxide concentration, thiab lwm yam., kom paub real-time xyuas thiab ntse tswj ntawm ib puag ncig hauv lub tsev cog khoom.
4. Tus tswj
Tus maub los ntawm IoT ntse tsev cog khoom yuav tsum muaj cov cua sov, qhov cua, dej, cua txias thiab lwm yam khoom siv nrog rau cov servers. Thaum lub kaw lus pom tias cov ntaub ntawv ib puag ncig uas tau sau ntau tshaj qhov tseem ceeb, tus tswj yuav cia li pib cov cuab yeej tswj hwm ib puag ncig los saib xyuas sab hauv tsev cog khoom. Ib puag ncig yog rhuab, watered, fertilized, ventilated, txias, thiab lwm yam., kom ua tiav tsis siv neeg ntse thiab meej tswj.
5. Main system
Lub hauv paus tseem ceeb ntawm IoT ntse tsev cog khoom yog ntsia rau hauv cov neeg rau zaub mov, uas yog lub luag haujlwm rau kev sau, nthuav tawm, sib piv thiab tswj cov ntaub ntawv ib puag ncig.
Intelligent Greenhouse Control System
Tsev cog khoom ntse tswj system yog muab tso rau pem hauv ntej thaum Internet ntawm Tej yam yog dav siv, tshwj xeeb tshaj yog tshwm sim ntawm Top Agricultural Internet ntawm yam. Raws li qhov no, kev tswj hwm thiab kev tswj hwm rau kev saib xyuas lub tsev cog khoom irrigation ib puag ncig yog tsim.
Lub kaw lus paub txog kev saib xyuas, tswj, ib puag ncig cov ntaub ntawv sau, txheeb xyuas, txheeb cais thiab kos duab ntawm cov cuab yeej siv dej hauv tsev cog khoom. Nws muaj qhov sib txuam zoo sib xws nrog WINDOWS, kev tswj hwm kev nco zoo meej thiab kev ua haujlwm zoo thiab nkag siab zoo. Cov xwm txheej tam sim no ntawm txhua lub tsev cog khoom tuaj yeem saib xyuas, suav nrog cov ntaub ntawv khaws cia ntawm qhov tsis xws li huab cua kub, huab cua humidity, illuminance, carbon dioxide, av kub, av noo, hluav taws xob conductivity, thiab lwm yam, nrog rau kev hloov ntawm txhua lub cuab yeej.
Kev khiav hauj lwm tsis ntawm txhua lub tsev xog paj tuaj yeem teeb tsa, xws li av av, av kub, conductivity, lub sij hawm thiab lwm yam tsis nyob rau hauv lub tsev cog khoom kom tswj tau lub hom phiaj tus nqi ntawm lub solenoid valve, dej twj tso kua mis, fertilization system, thiab lwm yam, los ntawm huab cua. Qhov kub thiab txias, huab cua noo, lub teeb, carbon dioxide, thiab lwm yam tsis tuaj yeem tswj tau lub hom phiaj tseem ceeb ntawm skylights, sab qhov rais, sab hauv sunshades, sab nrauv sunshades, kiv cua, ntaub ntub dej, everted windows, cua sov khoom, humidification khoom, carbon dioxide generators , thiab lwm yam thiab lub sijhawm qhib / kaw ntawm cov khoom siv, thiab lwm yam.
Kev Ntsuam Xyuas Tus Nqi ntawm Smart Greenhouse
Tus nqi ntawm lub tsev cog khoom ntse yog feem ntau muab faib ua plaub yam tseem ceeb: lub ntsiab ncej, npog cov khoom siv, cov cuab yeej siv, thiab tus nqi installation. Ntawm lawv, lub ntsiab thav duab yog nyob ntawm lub tsev cog khoom nrog qhov ntev ntawm 100 * 50 meters thiab qhov siab ntawm 6 meters. Tus nqi ntawm lub ntsiab ncej yog li ntawm 100-120 yuan ib square meter. Qhov siab dua tus ncej loj, tus nqi siab dua ntawm lub ntsiab ncej.
Cov ntaub ntawv npog feem ntau yog xa mus rau cov ntaub ntawv thermal rwb thaiv tsev ntawm lub façade thiab sab saum toj ntawm lub tsev cog khoom. Cov ntaub ntawv no yuav tsum muaj lub teeb pom kev zoo ua ntej, thiab thib ob kom muaj cov thermal rwb thaiv tsev zoo. Cov tsev cog khoom ntse feem ntau siv PC boards lossis iav ua rwb thaiv tsev cov ntaub ntawv, thiab tag nrho cov nqi ntawm cov ntaub ntawv npog yog kwv yees li 80-100 ib square meter. Ntawm lawv, PC boards feem ntau siv 8mm thiab 10mm. Cov iav tuaj yeem yog ib txheej tempered lossis ob txheej insulating iav. Ob-txheej insulating iav muaj zoo thermal rwb thaiv tsev nyhuv.
Txhawm rau suav nrog, tus nqi nruab nrab ntawm cov tsev cog khoom ntse yog nyob nruab nrab ntawm 370,450 yuan ib square meter, thiab cov khoom siv ntau dua, tus nqi siab dua.
